D60 Ring Lock Shoring Scaffolding Standard / Vertical

D60 Ring Lock Shoring Scaffolding Standard
D60 Ring Lock Shoring Scaffolding Standard D60 Ring Lock Shoring Scaffolding Standard D60 Ring Lock Shoring Scaffolding Standard D60 Ring Lock Shoring Scaffolding Standard

D60 Ring Lock Shoring Scaffolding Standard / Vertical

D60 Ring Lock High Load Shoring Scaffolding: It is used in Heavy Duty Load Requirement Construction Support, Including Infrastructure Scaffolding Like Bridge, High Speedway Construction, Industrial Scaffolding like Offshore Construction and High Load Concrete Formwork Temporary Scaffolding. The Vertical is made by O.D60x3.5mm high grade steel tube for heavy duty shoring purpose.


Scaffolding Components: Standard, Ledger, Diagonal Brace.

  • Item NO.:

    D60RS.S

  • Product Origin:

    Guangzhou, China

  • Shipping Port:

    Guangzhou, China

  • Payment:

    T/T, L/C at sight

  • Min order:

    500PCS

  • Color:

    Galvanized Colour
Inquire now
  • Product Detail

D60 Ring Lock High Load Shoring Scaffolding Standard / Vertical


Product Details:

Code Description Material Size Weight (kg) Weight (lbs)
D60RS.S.300 3.00M Standard Ø60.3x3.5mm; Q235-Q355 3000mm (9'10") 18.93  41.74
D60RS.S.250 2.50M Standard 2500mm (8'2") 15.93  35.13
D60RS.S.200 2.00M Standard 2000mm (6'7") 12.94  28.53
D60RS.S.150 1.50M Standard 1500mm (4'11") 9.94  21.92
D60RS.S.100 1.00M Standard 1000mm (3'3") 6.94  15.30
D60RS.S.050 0.50M Standard 500mm (1'8") 3.95  8.71




Features:

Tube Dimension: O.D60x3.5mm. Other tube thickness 4.0mm/3.25/3.0mm is also available by request.

Spigot Size: O.D 50x3x250mm

Steel Tube Grade: Q235-Q355

Rossette Distance: 500mm

Surface Finishing: Hot dip Galvanized; Powder Coated, Painted

Quality Standard: EN12810 / BS1139

Welding Process: Automatic welding
